Vishay - 564R60GAQ47. - Ceramic Capacitor, R3l, 47pf, 6kv
Vishay - 564R60GAQ47. - Ceramic Capacitor, R3l, 47pf, 6kv
Regular price
£2.29 GBP
Regular price
Sale price
£2.29 GBP
Unit price
/
per
The 564R60GAQ47 is a radial leaded lower voltage ceramic single-layer Disc Capacitor for DC and pulse high voltage applications. The 564R series capacitor consists of a ceramic disc of which both sides are silver plating. Connection leads are made of tinned copper having diameters of 0.032 inch. The capacitor may be supplied with radial kinked or straight leads having lead spacing of 0.375 inch. The standard tolerance is ±20%. Coating is made of resin coating or flame-retardant epoxy resin in accordance with UL94V-0.
Product Info
- Low losses
- High stability
- High capacitance in small sizes
Details | |
---|---|
Product Range: | 564R Series |
Capacitance: | 47pF |
Capacitance Tolerance: | ± 20% |
Dielectric Characteristic: | R3L |
Voltage Rating: | 6kV |
Capacitor Terminals: | Radial Leaded |
Packaging: | Each |
Lead Spacing: | 9.5mm |
Operating Temperature Min: | -25°C |
Operating Temperature Max: | 105°C |
Country of Origin: | Czech Republic |
