Toroidal Transformer, 2x 18V, 2.22 A, 80VA, 230V - VTX-146-080-118

Toroidal Transformer, 2x 18V, 2.22 A, 80VA, 230V - VTX-146-080-118

£22.29 GBP
£22.29 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

The VTX-146-080-118 from Multicomp is an open style toroidal transformer with flying leads. It features a single primary winding and dual secondary windings.

Product Info

  1. Power rating is 80VA
  2. Input voltage is 230VAC, typical regulation is 11%
  3. Output voltage is 2 x 18VAC, output current is 2.22A
  4. Low level radiated magnetic field
  5. Secondary windings can be connected in series or parallel or used independently
  6. Temperature rise is 50°C
  7. Dimension is 40mm x 90mm (Height x Diameter)

Details
Power Rating 80VA
Secondary Voltages 2 x 18V
Secondary Current Nom 2.22A
Transformer Mounting Chassis
Primary Voltages 230V
Product Range VTX Series
Product Contents: Transformer, Mounting kit.
Country of Origin: China

EAN:
Manufacturer Part Number:
