SMD Voltage Controlled Temperature Compensated Oscillator, VCTCXO, 10MHz, 0.5ppm, HCMOS, 3.3V, SMD, 7mm x 5mm - LFTVXO009912
SMD Voltage Controlled Temperature Compensated Oscillator, VCTCXO, 10MHz, 0.5ppm, HCMOS, 3.3V, SMD, 7mm x 5mm - LFTVXO009912
Regular price
£19.89 GBP
Regular price
Sale price
£19.89 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The LFTVXO009912 is a 7 x 5mm surface mount temperature compensated voltage Controlled Oscillator (TCVCXO) provides a high degree of frequency stability over a wide temperature range in a hermetically sealed ceramic package. Frequency range of 10 to 40MHz and frequency tolerance at ±0.5ppm.
Features
- Ageing ±1ppm per year (maximum)
- HCMOS output
- 3.3V Supply voltage
- 8ns Rise and fall time
| Specifications | |
|---|---|
| Frequency Nom | 10MHz |
| Frequency Stability + / - | 0.5ppm |
| Oscillator Output Compatibility | HCMOS |
| Supply Voltage Nom | 3.3V |
| Oscillator Case | SMD, 7mm x 5mm |
| Product Range | CFPT-126 Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Country of Origin: | Great Britain |
