LED Driver, 36V, 5.2A, 187.2W, IP65/IP67 - HLG-185H-36A
LED Driver, 36V, 5.2A, 187.2W, IP65/IP67 - HLG-185H-36A
Regular price
£78.39 GBP
Regular price
Sale price
£78.39 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
HLG-185H series is a 185W AC/DC LED driver featuring the dual mode constant voltage and constant current output. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is able to operate for -40°C to +90°C case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-185H is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.
Features
- Constant voltage and constant current mode output
- Metal housing with Class I design
- Built-in active PFC function
- IP65/IP67 rating for indoor or outdoor installations
- Function options: output adjustable via potentiometer
- 3-in-1 dimming, timer dimming
- 7-years warranty
| Specifications | |
|---|---|
| Output Power Max | 187.2W |
| Output Voltage Max | 36VDC |
| Output Current | 5.2A |
| LED Driver Mode | Constant Current, Constant Voltage |
| Input Voltage Min | 90V |
| Input Voltage Max | 305V |
| Product Range | HLG-185H |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | China |
