Isolated DIN Rail Mount DC/DC Converter, 12V, 1.25A, 15W - DDR-15G-12
Isolated DIN Rail Mount DC/DC Converter, 12V, 1.25A, 15W - DDR-15G-12
Couldn't load pickup availability
DDR-15G-12 is DDR- 15 series 15W DC-DC converter with the main features including DIN rail type easy installation, ultra-slim width (17.5), 4:1 ultra-wide input voltage, adjustable output voltage (±10%) and fully protective functions. It can be used for industrial control, security control, communication system, and another field. Suitable applications are DC buck/boost regulators, increasing system insulation level, and voltage drop compensation along the cable. Application includes semi conductor fabrication, factory automation, electro-mechanical, wireless network, telecom or datacom system. It includes short circuit protection, overload, over voltage, input reverse polarity, input under voltage protection. Approved by UL 62368-1, IEC 62368-1, AS/NZS 62368.1 EAC TP TC 004.
Features
- Output DC voltage is 12V, output rated current is 1.25A, output rated power is 15W
- Input voltage range from 9 to 36VDC, efficiency is 85%
- No minimum load requirement, cooling by free air convection
- Working temperature range from -40 to +85°C
- 3 years warranty
- Dimension (W x D x T) is 17.5 x 90 x 54.5mm
| Specifications | |
|---|---|
| Power Supply Applications | Railway |
| Input Ratio | 4:1 |
| Output Power Max | 15W |
| No. of Outputs | 1 Output |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 1 | 1.25A |
| Isolation Voltage | 4kV |
| DC / DC Converter Output Type | Fixed, Adjustable |
| Input Voltage DC Nom | 24V |
| Width | 17.5mm |
| Height | 90mm |
| Depth | 54.5mm |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| Product Range | DDR-15 Series |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | China |
