Fanless Industrial Power Supply, 55V, 8.9A, 500W - TGRF500-55
Fanless Industrial Power Supply, 55V, 8.9A, 500W - TGRF500-55
Regular price
£98.19 GBP
Regular price
Sale price
£98.19 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Enclosed AC-DC switching power supply. Features universal AC input and at the same time accepts DC input voltage. Offer excellent EMC performance and are widely used in areas of industrial, LED, street light control, electricity, security, telecoms, and smart home, etc.
Features
- Universal 85-305V AC, or 120-430V DC input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Narrow shape, semi-potted process, fanless design
- Operating ambient temperature range: -40C to +70C
- Low ripple and noise
- High efficiency, active PFC
- 150% peak load output for 1 second
- High I/O isolation test voltage up to 4kV AC
- Output short circuit, over-current, over-voltage, and over-temperature protection
- Operating altitude up to 5km
- Safety according to UL62368, EN60335, EN61558
| Specifications | |
|---|---|
| No. of Outputs | 1Outputs |
| Output Power Max | 500W |
| Output Voltage - Output 1 | 55V |
| Output Current - Output 1 | 8.9A |
| Input Voltage VAC | 85V AC to 305V AC |
| Power Supply Output Type | Fixed |
| Product Range | Tiger Power Supplies - TGRF500 Series |
| Country of Origin: | China |
