Enclosed Switching Power Supply, 24V, 13.4A, 320W - TGR320F-24
Enclosed Switching Power Supply, 24V, 13.4A, 320W - TGR320F-24
Regular price
£62.79 GBP
Regular price
Sale price
£62.79 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Enclosed AC/DC switching power supply that features AC input and at the same time accepts DC input voltage.
Features
- Widely used in areas of industrial, LED, street light control, electricity, security, telecoms, and smart home etc.
- Wide input voltage range - 85-305V AC, or 130-430V DC
- Accepts AC or DC input (dual-use of same terminal)
- Built-in active PFC function
- High I/O isolation test voltage up to 4kV AC
- Output short circuit, over-current, over-voltage, and over-temperature protection
- Compact size with a low, 1U profile
- LED indicator for power on
- Built-in DC fan
- Safety according to IEC/EN/UL62368, GB4943
- Emissions meets CISPR32/EN55032 Class B
| Specifications | |
|---|---|
| No. of Outputs | 1Outputs |
| Output Power Max | 320W |
| Output Voltage - Output 1 | 24V |
| Output Current - Output 1 | 13.4A |
| Input Voltage VAC | 85V AC to 305V AC |
| Power Supply Output Type | Fixed |
| Product Range | Tiger Power Supplies - TGR320F Series |
| Country of Origin: | China |
