AC/DC Enclosed Power Supply, 27V, 18.6A, 502.2W - RSP-500-27
AC/DC Enclosed Power Supply, 27V, 18.6A, 502.2W - RSP-500-27
Regular price
£160.19 GBP
Regular price
Sale price
£160.19 GBP
Unit price
/
per
RSP-500-27 is RSP-500 series 500W single output enclosed type AC/DC power supply. It offers the models with the DC output mostly demanded from the industry. Each model is cooled by the built-in fan with fan speed control, working for the temperature up to 70°C. This provides vast design flexibility by equipping various built-in functions such as remote ON-OFF control, remote sense, DC OK signal. It includes short circuit, overload, overvoltage, overtemperature protection. Application includes Factory control or automation apparatus test and measurement instrument, laser related machine, burn-in facility, RF application. Approved by UL62368-1, TUV BS EN/EN62368-1, AS/NZS 62368.1, EAC TP TC 004, CCC GB4943.1 , BSMI CNS14336-1.
Features
- Output DC voltage is 27V, output rated current is 18.6A, output rated power is 502.2W
- Typical efficiency is 89%
- Input voltage range from 88 to 264VAC, 124 to 370VDC
- Universal AC input / full range, built-in active PFC function
- High efficiency up to 90.5%, forced air cooling by built-in DC fan
- 3 years warranty
- Working temperature range from -35 to +70°C
- Dimension is (L x W x H) 230 x 127 x 40.5mm
Specifications | |
---|---|
Power Supply Applications | ITE |
No. of Outputs | 1Outputs |
Output Power Max | 502.2W |
Output Voltage - Output 1 | 27VDC |
Output Current - Output 1 | 18.6A |
Input Voltage VAC | 90V AC to 264V AC |
Power Supply Output Type | Adjustable, Fixed |
Product Range | RSP-500 Series |
Country of Origin: | China |
