AC/DC Enclosed Power Supply, 24V, 1.67A, 40W - ECE40US24-S
AC/DC Enclosed Power Supply, 24V, 1.67A, 40W - ECE40US24-S
Regular price
£80.29 GBP
Regular price
Sale price
£80.29 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
ECE40 series is encapsulated AC-DC power supply designed for low power ITE and industrial electronics applications. With approvals to world-wide safety standards, compliance with class B for conducted and radiated emissions and a 20%, 30s peak load capability. Not requiring any external components, these class II isolation parts benefit system designers with easy integration into a wide range of applications. Safety approvals are IEC60950-1:2005 Ed 2 / IEC62368-1:2014, UL 62368-1 and CAN/CSA C22.2 No. 62368-1-14, EN62368-1:2014/A11:2017.
Features
- Ultra compact size, chassis mount with screw terminal
- <0.3W no load input power
- Peak load capability
- Output power is 40W, output voltage is 24VDC
- Output current is 1.67 nominal, 85% efficiency
- Input voltage is 85-264VAC (120-370VDC) derate load from 100% at 90VAC to 90% at 85VAC
- Input frequency is 47-63Hz
- Operating temperature is -25°C to 70°C, derate linearly from 100% at 50°C to 50% at 70°C
- Trip and restart (hiccup mode) short circuit protection
- 3 year warranty
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1Outputs |
| Output Power Max | 40W |
| Output Voltage - Output 1 | 24VDC |
| Output Current - Output 1 | 1.67A |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Fixed |
| Product Range | ECE40 Series |
| Country of Origin: | China |
