AC/DC Encapsulated PCB Mount Power Supply, 12V, 1.08A, 10W - ECL10US12-E
AC/DC Encapsulated PCB Mount Power Supply, 12V, 1.08A, 10W - ECL10US12-E
Regular price
£51.09 GBP
Regular price
Sale price
£51.09 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The ECL series 5 to 30W AC/DC Power Supply with fixed and adjustable outputs.
Features
- Ultra Compact Size
- Single, Dual & Triple Outputs
- Open Frame PCB & Chassis Mount
- Encapsulated PCB & Chassis Mount
- Less Than 0.3W No Load Input Power
- Peak Load Capability
- Class II Construction
- See Technical Note for information about XP Power's plans for the UKCA Marking
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1 Output |
| Output Power Max | 10W |
| Output Voltage - Output 1 | 12VDC |
| Output Current - Output 1 | 830mA |
| Power Supply Output Type | Adjustable, Fixed |
| Input Voltage VAC | 85V AC to 264V AC |
| Width | 27.2mm |
| Height | 23mm |
| Depth | 52.4mm |
| Product Range | ECL10 Series |
| Country of Origin: | China |
