AC/DC Encapsulated Chassis Mount Power Supply, 5V/3A, +12V/0.63A, -12V/0.63A, 30W - ECL30UT02-S
AC/DC Encapsulated Chassis Mount Power Supply, 5V/3A, +12V/0.63A, -12V/0.63A, 30W - ECL30UT02-S
Regular price
£82.29 GBP
Regular price
Sale price
£82.29 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
ECL30UT02-S is an ECL series AC/DC converter with screw terminal. With approvals to international safety standards, compliance with class B for conducted & radiated emissions with no external components required and a 130%, 30s peak load capability, these class II isolation parts are easy to integrate into a wide range of applications. It includes overvoltage, overload, short-circuit protection. Certified by IEC60950-1:2005 Ed 2 / IEC62368-1:2014, UL 62368-1 and CAN/CSA C22.2 No. 62368-1-14, EN62368-1:2014/A11:2017.
Features
- I/P voltage from 85 to 264VAC, output voltage 1 is 5V (isolated output), output voltage 2 is +12V
- O/P voltage 3 is -12V, output current 1 is 3A, output current 2 is 0.63A, output current 3 is 0.63A
- Efficiency is 83%, ultra compact size
- Open frame PCB and chassis mount, <0.3W no load input power, peak load capability
- Isolation is 3000VAC (input to output)
- Typical switching frequency is 70KHz
- 3 year warranty
- Operating temperature range from -25°C to +70°C, derate linearly from 100% at +50°C to 50% at +70°C
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 3Outputs |
| Output Power Max | 30W |
| Output Voltage - Output 1 | 5VDC |
| Output Current - Output 1 | 3A |
| Output Voltage - Output 2 | 12VDC |
| Output Current - Output 2 | 630mA |
| Output Voltage - Output 3 | -12VDC |
| Output Current - Output 3 | 630mA |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Fixed |
| Product Range | ECL30 Series |
| Country of Origin: | China |
