AC/DC DIN Rail Power Supply, 48V, 2.5A, 120W - WDR-120-12
AC/DC DIN Rail Power Supply, 48V, 2.5A, 120W - WDR-120-12
Regular price
£94.99 GBP
Regular price
Sale price
£94.99 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
WDR-120-12 is WDR-120 series 120W single output industrial DIN RAIL power supply. It has built-in constant current limiting circuit and it can be installed on DIN rail TS-35/7.5 or 15. It includes short circuit, overload, overvoltage, overtemperature protection. Approved by UL508, EAC TP TC 004, IEC62368-1 CB by SIQ, design refer to BS EN/EN62368-1, AS/NZS 62368.1 (meet BS EN/EN60204-1), BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level.
Features
- Output DC voltage is 12V, output rated current is 10A, output rated power is 120W
- Typical efficiency is 89.5% / 400V
- Input voltage range from 180 to 550VAC, 254 to 780VDC
- Cooling by free air convection, built-in constant current limiting circuit
- Can be installed on DIN rail TS-35/7.5 or 15
- 100% full load burn-in test, built-in DC OK relay contact
- 3 years warranty
- Working temperature range from -25 to +70°C
- Dimension is (W x H x D) 40 x 125.2 x 113.5mm
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1 Output |
| Output Power Max | 120W |
| Output Voltage - Output 1 | 12VDC |
| Output Current - Output 1 | 10A |
| Input Voltage VAC | 180V AC to 550V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | WDR-120 Series |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | China |
