AC/DC DIN Rail Power Supply, 24V, 0.42A, 10W - MDR-10-24
AC/DC DIN Rail Power Supply, 24V, 0.42A, 10W - MDR-10-24
Regular price
£23.99 GBP
Regular price
Sale price
£23.99 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
MDR-10-24 is MDR-10 series 10W single output industrial DIN rail power supply. It has universal AC input/full range. It includes short circuit, overload, overvoltage, over temperature protection. Approved by UL508, TUV BS EN/EN62368-1, EAC TP TC 004, BSMI CNS14336-1, AS/NZS 60950.1.
Features
- Input voltage range from 85 to 264VAC, 120 to 373VDC, output DC voltage is 24V
- Output rated current is 0.42A, output rated power is 10W, typical efficiency is 84%
- Cooling by free air convection
- Built-in DC OK active signal, LED indicator for power on
- No load power consumption< 0.075W, 100% full load burn-in test
- 3 years warranty
- Working temperature range from -20 to +70°C
- Dimension is (W x H x D) 22.5 x 90 x 100mm
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1 Output |
| Output Power Max | 10W |
| Output Voltage - Output 1 | 24VDC |
| Output Current - Output 1 | 420mA |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Fixed |
| Product Range | MDR-10 Series |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | China |
