AC/DC DIN Rail Power Supply, 12V, 7.5A, 90W - MDR-100-12
AC/DC DIN Rail Power Supply, 12V, 7.5A, 90W - MDR-100-12
Regular price
£53.39 GBP
Regular price
Sale price
£53.39 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
MDR-100-12 is a MDR-100 series 90W single output industrial DIN rail power supply. It has universal AC input/full range. It features ZCS/ZVS technology to reduce power dissipation. It can be installed on DIN rail TS-35/7.5 or 15. It includes short circuit, overload, overvoltage, over temperature protection. Approved by UL508, TUV BS EN/EN62368-1, EAC TP TC 004, BSMI CNS14336-1, AS/NZS 60950.1.
Features
- Input voltage range from 85 to 264VAC, 120 to 373VDC, output DC voltage is 12V
- Output rated current is 7.5A, output rated power is 96W, typical efficiency is 86%
- Cooling by free air convection, LED indicator for power on
- DC OK relay contact, no load power consumption<1W
- 100% full load burn-in test
- 3 years warranty
- Working temperature range from -10 to +60°C
- Dimension is (W x D x H) 55 x 90 x 100mm
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1 Output |
| Output Power Max | 90W |
| Output Voltage - Output 1 | 12VDC |
| Output Current - Output 1 | 7.5A |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | MDR-100 Series |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | China |
