AC/DC DIN Rail Power Supply, 12V, 11.3A, 135.6W - HDR-150-12
AC/DC DIN Rail Power Supply, 12V, 11.3A, 135.6W - HDR-150-12
Couldn't load pickup availability
HDR-150-12 is a HDR-150 series economical ultra slim 150W DIN rail power supply. Adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 105mm (6SU) in width, which allows space saving inside the cabinets. It conforms to BS EN/ EN 61000- 3- 2, the norm the European union regulates for harmonic current. It designed with plastic housing that it can effectively prevent user from electric hazards. The complete protection functions and relevant certificates for home automations and industrial control apparatus, make it very competitive power supply solution for household and industrial applications. Application includes household control system, building automation, industrial control system, factory automation, electro-mechanical apparatus. Approved by IEC62368-1, UL62368-1, UL61010, TUV BS EN/EN61558-2-16, BS EN/EN61558-1, EAC TP TC 004, design refer to BS EN/EN50178, TUV BS EN/EN62368-1.
Features
- Output DC voltage is 12V, rated current is 10.2A (115VAC)/11.3A (230VAC)
- Output rated power is 122.4W (115VAC), 135.6W (230VAC), efficiency is 89%
- Input voltage range from 85 to 264VAC (277VAC operational ), 120 to 370VDC (390VDC operational )
- No load power consumption of <0.3W
- Isolation class II , DC output voltage adjustable, cooling by free air convection
- Over voltage category III, LED indicator for power on
- Short circuit, overload and overvoltage protection
- Working temperature range from -30 to +70°C
- 3 years warranty
- Dimension (W x H x D) is 105 x 90 x 54.5mm
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1 Output |
| Output Power Max | 135.6W |
| Output Voltage - Output 1 | 12VDC |
| Output Current - Output 1 | 11.3A |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | HDR-150 Series |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | China |
