8MHz Crystal, SMD, 11.4mm x 4.35mm, 10ppm, 18pF - 9C-8.000MEEJ-T
8MHz Crystal, SMD, 11.4mm x 4.35mm, 10ppm, 18pF - 9C-8.000MEEJ-T
Regular price
£1.79 GBP
Regular price
Sale price
£1.79 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 9C-8.000MEEJ-T is a 11.4 x 4.8mm SMD Quartz Crystal with highly mass production capabilities.
Features
- High Frequency Pullability and Low Equivalent Series Resistance
- Ageing ±3ppm Per Year Max
| Specifications | |
|---|---|
| Frequency Nom | 8MHz |
| Crystal Case | SMD, 11.4mm x 4.35mm |
| Frequency Stability + / - | 10ppm |
| Load Capacitance | 18pF |
| Frequency Tolerance + / - | 10ppm |
| Product Range | 9C Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Country of Origin: | China |
