16MHz Crystal, SMD, 11.4 x 4 .35mm, 30ppm, 18pF - 9C-16.000MAAJ-T
16MHz Crystal, SMD, 11.4 x 4 .35mm, 30ppm, 18pF - 9C-16.000MAAJ-T
Regular price
£1.59 GBP
Regular price
Sale price
£1.59 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 9C-16.000MAAJ-T is a 11.4 x 4.35mm SMD Quartz Crystal with high mass production capability. High frequency pullability and low equivalent series resistance. Frequency range of 3.2 to 90MHz, load capacitance of 18pF and frequency tolerance at ±30ppm.
Features
- Ageing ±3ppm per year (maximum)
- Fundamental mode
- 30R ESR
| Specifications | |
|---|---|
| Frequency Nom | 16MHz |
| Crystal Case | SMD, 11.4mm x 4.35mm |
| Frequency Stability + / - | 30ppm |
| Load Capacitance | 18pF |
| Frequency Tolerance + / - | 30ppm |
| Product Range | 9C Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Country of Origin: | China |
