CR1225 3V Lithium Button Cell Battery, 2-Pin Horizontal PCB Mount - CR1225 FH-LF
CR1225 3V Lithium Button Cell Battery, 2-Pin Horizontal PCB Mount - CR1225 FH-LF
Regular price
£3.39 GBP
Regular price
Sale price
£3.39 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The CR1225 FH-LF is a 1225 3V/48mAh Non-rechargeable Battery, lithium manganese dioxide technology with single cell, PCB-pin terminal, two-pin standard tabbed coin cells for horizontal mounting on PCBs, excellent solder ability to solder-plated areas, tin-plated solder area lead-free (>99.9% Sn) plated throughout, thickness minimum 2.5μm, solder ability according to MIL-STD 883C, method 2003.3.
Features
- Solder contacts stainless steel AISI 301, thickness 0.15mm
- Suitable for wave-soldering
| Specifications | |
|---|---|
| Battery Voltage | 3V |
| Battery Size Code | 1225 |
| Battery Technology | Lithium Manganese Dioxide |
| Battery Capacity | 48mAh |
| Battery Terminals | PCB Pins |
| External Diameter | 12.5mm |
| External Height | 7.2mm |
| External Width | 12.7mm |
| External Depth | 11mm |
| Pack Quantity | 1 |
| Weight | 1.1g |
| Battery IEC Code | CR1225 |
| Battery NEDA Code | 5020LC |
| Important Product Warning: | Coin batteries must be kept out of reach of children, consult a doctor immediately if swallowed. |
| Country of Origin: | Switzerland |
